Gen-set Controller InteliGen NTC BaseBox

Genset Controller InteliGen NTC BaseBox

Complex Parallel Gen-set Controller with Detachable Colour Display

Marine certified controller

Gen-set controller for both single and multiple gensets operating in standby or paralleling modes.

To be used in conjunction with detachable colour displays InteliVision 5, InteliVision 8 or InteliVision 12Touch

Support of engines with ECU (Electronic Control Unit)

Complete integrated gen-set solution and signal sharing via CAN bus – minimum external components needed

Many communication options - Ethernet connection (RJ45), USB 2.0 slave interface, 1× RS232 / 2× RS485 interface with Modbus protocol support; Analog / GSM / ISDN / CDMA modem communication support; SMS messages; ECU Modbus interface; isolated secondary RS485

AirGate support – easy remote supervising and servicing

Automatic synchronizing and power control (via speed governor or ECU)

AMF function, Baseload, Import / Export, Peak shaving, Voltage and PF control (AVR)

Generator measurement: U, I, Hz, kW, kVAr, kVA, PF, kWh, kVAhr

Mains measurement: U, I, Hz, kW, kVAr, PF

Selectable measurement ranges for AC voltages and currents – 120 / 277 V, 0–1 / 0–5 A

True RMS (TRMS) is used with Voltage, Current and Power measurement

Inputs and outputs configurable for various customer needs

Bipolar binary outputs - possibility to use BO as High or Low side switch

Controller redundancy

Event-based history (up to 1000 records) with customer-selectable list of stored values; RTC; statistic values

Integrated PLC programmable functions

Integrated fixed and configurable protections

DIN-Rail mount

Customized firmware solution

With Solution of Application support - manage up to 992 Gen-sets in Extended Multiple Gen-set Application (Bank Controller)
