APECS 0225 Linear Actuators 36730
APECS 0225 Linear Actuators 36730
|
Input Voltage Range: |
12 Vdc 24 Vdc |
|
Nominal Steady State Current: |
2.5 A 1.0 A |
|
Maximum At Stall @ 75°F (24°C): @ 250°F (125°C): |
5.4 A 3.0 A 3.9 A 2.0 A |
Performance
|
Resistance 12 Vdc:24 Vdc: |
1.8 Ohm 7.2 Ohm |
|
Force w/o Internal Spring: |
6.5 lbf (28.9 N) |
|
Work w/o Spring: |
0.54 ft-lb (0.734 N-m) |
|
Shaft Travel: |
0.975-1.025” (24.76-26.03 mm) |
|
Response Time Nominal for 63% of Stroke: |
0.05 sec ON Time 0.035 sec OFF Time |
|
Operating Temperature: |
-65°F to +250°F (-55°C to +125°C) |
|
Vibration: |
5 to 500 Hz Curve L per Mil-Std 810C |
|
Case: |
Corrosion resistant, plated steel housing and mounting base/flange |
|
Sealing: |
Oil, water, and dust resistant |
|
Weight: |
2.7 lbs (1.22 kg) |
