Genset Controller InteliCompact NT SPtM

Genset Controller InteliCompact NT SPtM

Genset Controller for Gensets in Parallel to Mains Applications

Compact genset controller for single genset operating in Parallel to Mains mode or Auto Mains Failure (AMF) mode with no-break transfers

Meets all requirements for AMF applications

Forward and reverse synchronizing

Peak shaving, Peak lopping

Load, speed, voltage and power factor control

High tariff avoidance

Mains import/export

Full gen-set monitoring and protection

Possibility to connect up to 8 gauges to display engine values

True voltage and current RMS measurement

Outstanding EFI engine support (CAN/J1939, RS232/Modbus) with diagnostic messages in plain text

3 phase generator voltage and current measurement

3 phase mains voltage measurement

3 phase power measurement

1 phase mains current measurement

Additional 7 binary inputs/outputs via IC-NT CT-BIO7 (in total up to 16 inputs/15 outputs)

3 analog inputs

RS232, RS485, USB, Modbus, GSM/Analog Modem, Internet communication*

GPRS communication and IC-NT RD (remote display) software

AirGate and WebSupervisor support

Support of active SMS Events or Commands

Event and performance log

2 languages (user changeable)

IC-NT CT-BIO7 extension plug-in module included

* relevant plug-in module is required
